BioEntry P2

Compact IP Fingerprint Device.

BioEntry P2
Request a Quote ⇓ Download Brochure

Overview

BioEntry P2 is Suprema's compact fingerprint access device, engineered for installations where a slim, unobtrusive biometric reader is required without sacrificing security. At 50.1 × 164 × 38 mm it fits standard mullion frames and narrow wall positions, while IP65 rating ensures reliable operation in indoor and semi-outdoor environments. With full BioStar 2 integration, Wiegand and RS-485/OSDP output, BioEntry P2 slides into both new deployments and retrofits onto existing third-party access controllers.

Key Features

Compact mullion form factor

50.1 × 164 × 38 mm profile fits standard door frames and narrow mounting positions without exposed cable runs.

MINEX-certified fingerprint

ISO 19794-2 / ANSI 378 fingerprint algorithm with software-based liveness detection.

Multi-technology RFID

Supports 125 kHz EM / HID Prox and 13.56 MHz MIFARE / DESFire / iCLASS in a single reader.

IP65 rated

Dust-tight and water-resistant for indoor lobbies, stairwells and semi-exposed positions.

Specifications

General
CPU 1.0 GHz
RAM / Flash 64 MB RAM / 8 GB Flash
Crypto Chip Supported
Dimensions 50.1 × 164 × 38 mm
Weight 162 g (device) + 39 g (bracket)
Operating Temperature -20 °C to 50 °C
Storage Temperature -40 °C to 70 °C
Operating Humidity 0–80%
IP Rating IP65
Authentication
Fingerprint Standard ISO 19794-2 / ANSI 378 (MINEX certified)
Live Detection Software
Fingerprint Capacity (1:N / 1:1) 10,000
Card Capacity 10,000
Max Users 10,000
Event Log 1,000,000 text
Card Types 125 kHz EM / HID Prox · 13.56 MHz MIFARE / DESFire EV1-3 / FeliCa / iCLASS SE/SR/Seos
Connectivity
Ethernet Supported (TCP/UDP)
RS-485 OSDP supported
Wiegand 1ch in/out selectable + 2ch inputs
Relay 1 relay output
Power 12 V DC Max 0.2 A
PoE Supported
