RFID Readers

X-Station 2

Multi-credential RFID terminal — RFID, mobile, QR and PIN in one ultra-slim reader.

Datasheet Enquire

MULTI-CREDENTIAL

Flexible multi-credential identification.

X-Station 2 reads QR/barcode, NFC, BLE mobile, 125 kHz EM and 13.56 MHz MIFARE/DESFire/FeliCa — and optionally HID iCLASS and Seos. One terminal covers every credential type your tenants, contractors and visitors might present, with PIN and on-screen scrambled keypad for two-factor scenarios.

RFID COMPATIBILITY

Comprehensive RFID card compatibility.

Beyond standard EM and MIFARE/DESFire/FeliCa, the -A model adds HID iCLASS SE/SR/Seos and HID Prox — drop X-Station 2 into existing HID deployments without re-issuing credentials. Read ranges up to 50 mm for MIFARE/DESFire/EM and 30 mm for FeliCa.

USABILITY

Intuitive UI on a 4-inch touchscreen.

480 × 800 colour IPS display with multi-tone buzzer, multi-colour LED feedback and a 2 MP camera for image-log capture on every authentication. Visitors and casual users find it without instruction — staff get instant on-screen confirmation.

Specifications

General
CPU	1.5 GHz Quad Core
RAM / Flash	1 GB RAM / 16 GB Flash
Crypto Chip	Supported
Display	4" IPS colour LCD (480 × 800 px)
Camera	CMOS 2M px (1600 × 1200)
Dimensions	82 × 159 × 25.9 mm (RFID-only)
Weight	Approx. 290 g (device)
Operating Temperature	-20 °C to 50 °C
Storage Temperature	-40 °C to 70 °C
Operating Humidity	0–80% non-condensing
Storage Humidity	0-90% non-condensing
IP Rating	IP65

Credentials
Max Users	500,000
Text Log	5,000,000
Image Log	50,000
RFID (Low Frequency)	125 kHz EM (· HID Prox / iCLASS on -A models)
RFID (High Frequency)	13.56 MHz MIFARE / MIFARE Plus / DESFire EV1-3 / FeliCa
RFID Read Range	MIFARE / DESFire / EM: 50 mm · FeliCa: 30 mm
Mobile	NFC · BLE
QR / Barcode	Supported (software-based)
PIN	Supported

Connectivity
Ethernet	10/100 Mbps (TCP/UDP)
RS-485	1ch Master/Slave — OSDP V2 compliant
Wiegand	1ch in/out (selectable)
Inputs	2ch
Relay	1 relay
USB	USB 2.0 Host
PoE	IEEE 802.3af
Power	12 V DC Max 0.6 A or 24 V DC Max 0.4 A

DOWNLOAD

X-Station 2 datasheet

Full specifications, dimensions, certifications and ordering options — official Suprema datasheet PDF, mirrored locally for Suprema South Africa customers.

Preview ⇩ Datasheet (PDF) Request more docs
